Product Description

Technical Parameters

ModelLoad Capacity(KG)Min Height (MM)Lifting Height (MM)Max Platform Height(MM)Platform Size(MM)Net weight (KG)
Single Scissor Lift table




SFT100110002057859901300×820160
SFT100210002057859901600×1000186
SFT2001200023077010001300×850235
SFT4001400024081010501700×1200375
Double Scissor Lift table




DFT10001000305147517801300X820210
DFT20002000350143017801300X850295
Three Scissor Lift table




TFT10001000470253030001700x1000450
TFT20002000560244030001700x1000750
Four Scissor Lift table




FFT4000400600354041401700x1000800


Features of scissor lift table :

Heavy-duty design, use AC power supply, customized according to the requirement

• Imported high-quality pumping station,makes the cargo lift stable and powerful

• There is a safety barrier device(aluminum sensor) under the table top. When the table top drops and encounters obstacles, it stops descending immediately to ensure safety.

• Detachable lifting ring, convenient for platform truck transportation and installation

• Self-lubricating bushings are provided on the rotating pivot, which is maintenance-free

• Adopt anti-pinch scissor design to prevent pinch injury, with overload protection function, more reliable and safer

• The hydraulic system is equipped with explosion-proof valves, which can prevent the platform truck from sliding down rapidly when the tubing bursts

• Equipped with safety wedge block for easy maintenance

• Widely used in manufacturing, maintenance and other industries,suitable for supporting the use of forklift/stacker/pallet trucks in warehousing, logistics, production lines and other places



More models pls contact us for detailed information. If our standard model can not meet your demand, then just let us know your detailed requirement,like goods weight,platform size and lifting height etc,then Futlift will design it specially and offer you the best solution.
